The internal structure of outline dimension drawing
Technical parameters
Unit: mm
|
Model no. |
A |
B |
C |
|
2W-025-06 |
39 |
42 |
74 |
|
2W-025-08 |
39 |
42 |
74 |
|
2W-040-08 |
51 |
42 |
74 |
|
2W-040-10 |
62 |
52 |
85 |
|
2W-160-10 |
51 |
52 |
85 |
|
2W-160-15small |
62 |
55 |
102 |
|
2W-160-15 |
67 |
55 |
102 |
|
2W-200-20 |
86 |
55 |
113 |
|
2W-250-25 |
90 |
73 |
117 |
|
2W-320-32 |
106 |
87 |
130 |
|
2W-400-40 |
123 |
93 |
1 64 |
|
2W-500-50 |
A |
B |
176 |
Structure parameters
|
Model NO. |
2W-025-06 |
2W-025-08 |
2W-040-10 |
2W-160-10 |
2W-160-15 |
2W-200-20 |
2W-250-25 |
2W-320-32 |
2W-400-40 |
2W-500-50 |
|
Pipe Size |
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
1" |
1 1/4" |
11/2" |
2” |
|
|
Orifice size |
2.5mm |
4mm |
4mm |
16mm |
16mm |
20mm |
25mm |
32mm |
40mm |
50mm |
|
CV value |
0.23 |
0.6 |
4.8 |
4.8 |
7.6 |
12 |
24 |
29 |
48 |
|
|
Fluid |
Air water oil,the neutral gasliquid |
|||||||||
|
Service voltage |
AC380V AC220V AC110V AC24V DC24V DC12V allow ±10% |
|||||||||
|
Operating |
direct acting |
type |
Normally Closed |
|||||||
|
Body Material |
Brass |
viscosity |
Below 20CST |
|||||||
|
Working pressure |
Water,air :0~10kgf/cm² Oil:0~7kgf/cm² |
|||||||||
|
Material of seal |
Standard: below 80℃ fluid temperature use NBR. below 120℃ use EPDM. below 150℃ use VITON |
|||||||||
Company Advantages
· Tianfei High-Tech motorized valve supplier comes out after consulting people from outside the company.
· The product meets rigorous standards for quality and consistency.
· This product has achieved good results in practical applications.
Company Features
· Tianjin Tianfei High-Tech Valve Co., Ltd. plays an active role in the manufacturing of motorized valve supplier. Now, we are regarded as one of the best suppliers in the industry.
· Thanks to our industrious team, our motorized valve supplier has become more of an attract.
· Tianjin Tianfei High-Tech Valve Co., Ltd. always clings to long-term development by providing customers with superior motorized valve supplier. Inquiry!
Application of the Product
The motorized valve supplier produced by our company can be used in many fields.
Tianfei High-Tech is dedicated to providing professional, efficient and economical solutions for customers, so as to meet customers' needs to the greatest extent.
