Hot3 4 Inch Motorized Ball Valve Tianfei High-Tech Brand-1

Inquiry

Product details of the 3 4 inch motorized ball valve

Product Information

Tianfei High-Tech 3 4 inch motorized ball valve is manufactured using the most advanced technology and most sophisticated equipment. This product has excellent performance, durability and usability. As a professional 3 4 inch motorized ball valve supplier, Tianfei High-Tech always offers the first-rate products.

Feature

1．Powerful function: intelligently, proportionally type, switch type, it has all kinds of signal output type you wish for;

2．Small volume: the volume is just about thirty percent of product of same kind;

3．Be portable: its weight is just about thirty percent of product of same king;

4．Beautiful appearance: outer casing is pressure-cast with Al alloy, fine and evenly, reducing electromag-netic disturbance;

5．Wear-rseistance: the worm-wheel output axle integration design avoids the stitch closure in connection place of key, the transmission precision high, forged with special copper alloy, with features of high strength and super wear-resistance;

6．Safety quarantee: has passed AC1500v pressure-withstand test, F grade of insulated electric machine, which guarantees the operation safety;

7．Easily forming complete set: adopting single-phase power, simplifying wire connection from outside also can be 380V DC power;

8．Using simply: don’t need add-oil, point-check, and owns performance of waterproof and antirust, could be installed at any angle;

9．Protection appliance: double position-limiting, over-hot protection, overload protection(optionally);

10．Many kinds of speed: whole stroke time has many kinds as 9s,13s,15s,30s,100s(before dispatching from the factory in order to establish);

11．Antirust and anticorrosion: complete-machine support, both coupling and screw are made of stainless steel;

12．Intelligently numerically-control: the function of intelligently controlling module height is integrated into electric appliance body, the externally-connected localizer is not required. Numerically setting, numerically regulating, highly accurate, self-diagnosis, many functions on one machine.

Product fittings

未标题-2 (6)

未标题-5 (9)

未标题-6 (2)

未标题-20 (2)

Shade Diagram

Wiring diagram

CR11 （AC passive contact type）

1.Connecting SW and OPEN, the valve opens, getting the position,power off automatically, black and green wires output the open signal, the valve remains fully open position. 2.Connecting SW and CLOSE, the valve closes, getting the position, power off automatically,black and red wires output the close signal, the valve remains fully close position

CR12 （ AC active contact type ）

1.Connecting SW and OPEN, the valve opens, getting the position,power off automatically, yellow and green wires output the open signal, the valve remains fully open position. 2.Connecting SW and CLOSE, the valve closes, getting the position, power off automatically,yellow and red wires output the close signal, the valve remains fully close position

CR13 （DC passtive contact type ）

AC380v （standard wiring diagram )

1.KO close,valve open,getting the position,internal automatically power off 2.KC close,valve close,getting the position,internal automatically power off

AC380v （passive contact type wiring diagram ）

1.KO close,valve open,getting the position,internal automatically power off,terminal 8 output open position signal 2.KC close,valve close,getting the position,internal automatically power off,terminal 9 output close position signal

Intelligent modulating type

1.Power(L&N) 2.Input signal,output signal
