Manufactured using premium quality materials and sophisticated technology, Tianfei High-Tech electric valve supplier stands for the excellent craftsmanship in the industry. With the support from our experts, the product is in strict compliance with the industry quality standards. The electric valve supplier produced by Tianfei High-Tech is widely used in industry. This product is widely applied to the industry for its great growth prospects.

Product Information

Compared with other products in the same industry, Tianfei High-Tech's electric valve supplier has the following characteristics.

Feature

1．Powerful function: intelligently, proportionally type, switch type, it has all kinds of signal output type you wish for;

2．Small volume: the volume is just about thirty percent of product of same kind;

3．Be portable: its weight is just about thirty percent of product of same king;

4．Beautiful appearance: outer casing is pressure-cast with Al alloy, fine and evenly, reducing electromag-netic disturbance;

5．Wear-rseistance: the worm-wheel output axle integration design avoids the stitch closure in connection place of key, the transmission precision high, forged with special copper alloy, with features of high strength and super wear-resistance;

6．Safety quarantee: has passed AC1500v pressure-withstand test, F grade of insulated electric machine, which guarantees the operation safety;

7．Easily forming complete set: adopting single-phase power, simplifying wire connection from outside also can be 380V DC power;

8．Using simply: don’t need add-oil, point-check, and owns performance of waterproof and antirust, could be installed at any angle;

9．Protection appliance: double position-limiting, over-hot protection, overload protection(optionally);

10．Many kinds of speed: whole stroke time has many kinds as 9s,13s,15s,30s,100s(before dispatching from the factory in order to establish);

11．Antirust and anticorrosion: complete-machine support, both coupling and screw are made of stainless steel;

12．Intelligently numerically-control: the function of intelligently controlling module height is integrated into electric appliance body, the externally-connected localizer is not required. Numerically setting, numerically regulating, highly accurate, self-diagnosis, many functions on one machine.

Product fittings

IMG_8791

IMG_8794

IMG_8802

IMG_8902

IMG_8905

IMG_8903

Shade Diagram

Wiring diagram

CR11 （AC passive contact type）

1.Connecting SW and OPEN, the valve opens, getting the position,power off automatically, black and green wires output the open signal, the valve remains fully open position. 2.Connecting SW and CLOSE, the valve closes, getting the position, power off automatically,black and red wires output the close signal, the valve remains fully close position

CR12 （ AC active contact type ）

1.Connecting SW and OPEN, the valve opens, getting the position,power off automatically, yellow and green wires output the open signal, the valve remains fully open position. 2.Connecting SW and CLOSE, the valve closes, getting the position, power off automatically,yellow and red wires output the close signal, the valve remains fully close position

CR13 （DC passtive contact type ）

AC380v （standard wiring diagram )

1.KO close,valve open,getting the position,internal automatically power off 2.KC close,valve close,getting the position,internal automatically power off

AC380v （passive contact type wiring diagram ）

1.KO close,valve open,getting the position,internal automatically power off,terminal 8 output open position signal 2.KC close,valve close,getting the position,internal automatically power off,terminal 9 output close position signal

Intelligent modulating type

1.Power(L&N) 2.Input signal,output signal

Company Advantages

Tianjin Tianfei High-Tech Valve Co., Ltd. is located in tian jin and is a company that mainly sells motorized valve,intelligent valve. Tianfei High-Tech's brand Tianfei High-Tech is created after the exploration for we take product differentiation as a long-term development strategy for our enterprise Tianfei High-Tech has advanced technical support and perfect after-sales service. Customers can select and purchase without worries. With years of experience in valve manufacturing, Tianfei High-Tech has advanced technology and great production efficiency. According to customers' needs, we could design and produce various motorized valve,intelligent valve as well as provide quality custom service.
Tianfei High-Tech's motorized valve,intelligent valve is available with multiple types, diverse specifications, wide applications and affordable price. Feel free to contact us to order!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
